German-style 1-Port Keystone Faceplate VCELINK
| Quantity | Price Per Unit / Pack | Savings |
|---|---|---|
| 10-49 | $11.88 | 5% |
| 50-99 | $11.25 | 10% |
| 100+ | $10.00 | 20% |
Free Shipping for Orders Over $10.99 in the US.
Fast shipping. Know More at Delivery & Return.
For more information, please send us an inquiry or email us.
Features:
- 1-gang, 1-port Angled Keystone Faceplate
- Metal Bracket Material: Zinc Alloy
- Integrated Dust Protection Cover
- A Label Pocket for Cable Management
- Worldwide Shipping & Fast Delivery
- 12-month Warranty & Lifetime Product Support
Pairs Perfectly With
Description
VCELINK Single-Gang Keystone Faceplate is compatible with German-style back boxes and keystone jacks, ideal for structured cabling systems. The wall plate features a label area for easy and clear identification of your connection. The faceplate also comes with a durable frame and slope to enhance cable management by improving bend radius and protecting modules from dust. It is ideal for home or office setups with support for data and other communication connections.
If you have requirements for bulk purchasing or customized services, contact us or email us.
Specifications
| Product Type | Germany-Style Wall Plate |
| Style | White; 1-Port |
| Components | Plastic Wall Plate, Metal Bracket |
| Plastic Wall Plate Material | ABS |
| Metal Bracket Material | Zinc Alloy |
| Plastic Wall Plate Size | 3.15 in * 3.15 in * 0.35 in (79.90 mm * 79.90 mm * 8.80 mm) |
| Metal Bracket Size | 2.76 in * 2.76 in * 0.70 in (70.00 mm * 70.00 mm * 17.90 mm) |
| Termination Type | Keystone Module |
| Operating Temperature | -13℉～158℉ (-25℃～70℃) |
| Operating Humidity | ≤85% (Temperature 185℉± 37.40℉, 85℃±3℃) |
| Frequency Range | 1～500 MHz |
| Working Voltage | 125 V |
| Puncture Test | DC 1000 V (AC 750 V) 1 Min without Breakdown and Arc-over |
| Near-End CrossTlk (NEXT) | ≥ 4 dB |
| Insulation resistance | Initial Value ≥ 100 MΩ, After Constant Humidity and Heat Test ≥ 100 MΩ |
Features
Sloped-port Design
The sloped design enables the convenient routing of cables and helps reduce the strain on connectors.
Easy Installation
The German-style wall plate can be easily installed and secured on the wall with the included mounting screws.
Dust-free Protection
The 1-port faceplate features a dust cover for a neat and clean appearance, protecting connections from debris and moisture.
Wide Applications
-The flush-mounted data socket is suitable for RJ45 patch cables, network cables, Ethernet cables, and LAN cables;
-The white faceplate features a sleek and modern design that seamlessly integrates into any environment;
-Ideal for residential, office, or commercial network installations.
